Catalog Home > Turbos & Housings > Garrett GTX Gen2 > Garrett GTX3576R Gen2 Variants

Supercore, Garrett, Gen2 GTX3576R, P/N: 851154-5003S

Quantity in Basket: None
Code: GRT-TBO-M37
Price: $2,175.91
Shipping Weight: 3.00 pounds

Quantity:

Supercore, Garrett, Gen2 GTX3576R, P/N: 851154-5003S


PRODUCT DESCRIPTION:
    Garrett GEN2 GTX3576R dual ball bearing SuperCore (P/N: 851154-5003S) with ultra high flow Gen2 compressor wheel. NO TURBINE HOUSING (Supercore). Advanced GEN2 billet compressor wheel capable of 750HP!
PRODUCT FEATURES:
  • Advanced aerodynamics & ultra high flow Garrett GTX GEN2 compressor wheel
  • Forged billet aluminum compressor wheel
  • Dual ball bearing CHRA rotating assembly
PRODUCT SPECIFICATIONS:
  • Compressor Wheel Inducer: 58mm
  • Compressor Wheel Exducer: 76mm
  • Compressor Wheel Trim: 58
  • Turbine Wheel Inducer: 68mm
  • Turbine Wheel Exducer: 62mm
  • Turbine Wheel Trim: 84
COOLANT (WATER) & OIL FITTINGS, FLANGES, AND COMPONENTS SOLUTIONS: COMPRESSOR & TURBINE MAPS: APPLICABLE GARRETT PART NUMBERS:
  • Supercore P/N: 851154-5003S
