03.05.24 GARRETT Released: PowerMAX 550HP for the MK8 GOLF R... CLICK HERE TO CHECK OUT...
03.21.24 Recent product uploads... CLICK HERE TO CHECK OUT...

Catalog Home > Vehicle Specific > VW GTI 2020+ (MK8)

GARRETT PowerMAX 550HP, MK8 GOLF R and others MY 2020+ VW 2.0L TSI EA888 EVO4 engine PN 921474-5001S

Quantity in Basket: None
Code: GRT-TBO-S29
Price: $1,999.95
Shipping Weight: 10.00 pounds

Quantity:

GARRETT PowerMAX 550HP, MK8 GOLF R and others MY 2020+ VW 2.0L TSI EA888 EVO4 engine PN 921474-5001S
GARRETT PowerMAX 550HP, MK8 GOLF R and others MY 2020+ VW 2.0L TSI EA888 EVO4 engine Garrett Turbo PN 921474-5001S



Download PDF

Download INSTALLATION MANUAL (coming soon)
Product Features:
  • Direct-Fit 2020+ Volkswagen Golf R | Audi | Cupra | 2.0L TSI EA888 EVO4
  • Complete assembly with calibrated electric actuator for OE fitment
  • 550BHP | 410kW turbo capability (on-vehicle results 520BHP | 383kW with conservative tune)
  • +20% compressor flow compared to OE turbo
  • +37% turbine flow compared to OE turbo
  • Customized modern compressor wheel aero for application
  • Modern gasoline turbine wheel aerodynamics constructed of Mar-M alloy rated for up to 1050C
  • Stainless steel turbine housing rated for up to 1050C
  • Fully machined speed sensor port
  • Recommended Speed Sensor Kit sold separately: ATP-ACS-032
  • Integrated thrust bearing - reinforced for application
On Vehicle Performance Testing Results: Vehicle Fitment List: Compressor & Turbine Maps: Garrett Turbo Part Number:
  • 921474-5001S


Related Item(s)
Related Parts:
Code Name Price
ATP-ACS-032 Garrett Turbocharger *G-Series* Speed Sensor Kit (With Gauge) P/N: 781328-0003 $496.50
ATP-ACS-033 Garrett Turbocharger *G-Series* Speed Sensor Pro Kit (No Gauge) P/N: 781328-0004 $260.52
ATP-ACS-047 Garrett 923586-0003, Turbo Speed/Boost Module Kit (w/ Flanged Sensor - G-Series) G-SMART / GSMART $539.95
