Catalog Home > V-Band > Flanges > Flanges/Fittings for Garrett Housings



Flanges/Fittings for Garrett Housings <<Back
Related: TiAl Flanges & Clamps


Flanges
GT25 GT/GTX28
Flanges
GT/GTX 30/35
Flanges
GT37
Flanges
GT/GTX40
Flanges
GT/GTX 42/45
Flanges
GT/GTX 47/50
Flanges
GT/GTX55

Flanges & Fittings
G Series - G25 G30 G35
Flanges & Fittings
G Series - G42 G45

Stainless MANIFOLD SIDE Flange and Clamp set (1 each) for Garrett Undivided V-band Entry Housing

Code: CLC-CLA-040
Price: $54.00
Stainless DOWNPIPE SIDE Flange and Clamp set 3" GT V-band (w/protruded lip at ID) 3.55" / 90mm OD

Code: CLC-CLA-024
Price: $49.00
Stainless 3" DOWNPIPE SIDE FLANGE w/ protruded lip for Garrett "GT" 3" V-band (3.55" / 90mm OD)

Code: ATP-FLS-105
Price: $26.00
CLAMP, V-Band DOWNPIPE SIDE 3" Garrett "GT V-Band" Turbine Housing w/ 90mm OD Flange GTX G25 G30 G35

Code: CLC-CLA-048
Price: $22.95
FLANGE, Stainless 3" GT V-Band w/ 78mm protruded lip, fits Garrett Housings with 90mm (3.55”) OD

Code: ATP-FLS-245
Price: $26.00
DOWNPIPE FLANGE, Stainless 3" GT V-Band w/ 81mm protruded lip, Garrett Housings with 90mm (3.55”) OD

Code: ATP-FLS-246
Price: $26.00
Stainless Downpipe Flange and Clamp set 3" GT V-band (w/Protruded 78mm lip at the ID) 90mm OD

Code: CLC-CLA-051
Price: $49.00
FLANGE AND CLAMP SET, Stainless Downpipe 3" GT V-band (w/ Protruded 81mm lip at the ID) 90mm OD

Code: CLC-CLA-052
Price: $49.00
V-Band Clamp - 4" - For 4.75" OD Flanges

Code: CLC-CLA-014
Price: $19.95
SIMPLIFIED Flange, 2.5" / T31 V-Band STAINLESS STEEL (3.10" OD flange, Grooved for 2.5" OD Tube)

Code: ATP-FLS-169
Price: $19.95
SIMPLIFIED Flange, 2.5" / T31 V-Band MILD STEEL (3.10" OD flange, Grooved for 2.5" OD Tube)

Code: ATP-FLS-166
Price: $15.95
DOUBLE STEPPED Flange, 2.5" / T31 V-Band STAINLESS (3.10" OD flange, Grooved for 2.5" & 3" OD Tube)

Code: ATP-FLS-099
Price: $19.95
DOUBLE STEPPED Flange, 2.5" / T31 V-Band MILD STEEL (3.10" OD flange, Grooved for 2.5" & 3" OD Tube)

Code: ATP-FLS-073
Price: $15.95
90mm OD V-Band (Tial / 3" GTVB) to 4" Pipe - Machined Transition Piece (Stainless Steel)

Code: ATP-FLS-295
Price: $29.00
Standard 3" V-Band (3.75" Flange OD) to 4" Pipe - Machined Transition Piece (Stainless Steel)

Code: ATP-FLS-220
Price: $29.00
Flange, Steel Weld, 3" V-band, T4 Turbine Hsg, Convert discharge to 81mm centering vband

Code: ATP-FLS-083
Price: $28.00
Flat (NO PROTRUDED LIP), 3" Stainless Weld Flange, V-band, 304 stainless, 3.55" OD (3-5/8" OK)

Code: ATP-FLS-360
Price: $19.95
3" Stainless Weld Flange, V-band- Machined 304 stainless, 90mm(3.55) OD,81mm FEMALE groove

Code: ATP-FLS-361
Price: $19.95
Stainless Steel V-Band Clamp, 4.50" Max diameter, for Garrett Comp V-Band out, Large frame

Code: CLC-CLA-277
Price: $19.95
Flange, Stainless, V-band, 5", FLAT, Mates to standard 5" v-band flange

Code: ATP-FLS-382
Price: $34.00
DOWNPIPE FLANGE, TITANIUM 3" GT V-Band w/ 81mm protruded lip, Garrett Housings with 90mm (3.55”) OD

Code: ATP-FLS-387
Price: $69.00
TITANIUM 3" V-Band Outlet Flange (Downpipe); Garrett G25 G30 G35 - G Series

Code: ATP-FLS-400
Price: $69.00
